DZQ-700L External Strip Vacuum Packaging Machine

Description
DZQ-700L external strip vacuum packing machine is used for all kinds of electronic products and metal processing parts of the vacuum packaging, which can prevent damp, oxidation and coloration.
Application OF Vacuum Sealer
The external strip vacuum packing machine is especially suitable for vacuum packing sealing of large packing bag, such as meat, grain, herbs, medicines, chemicals, powder goods, electronic products.

Technical characters OF Vacuum Sealer
1. TAIWAN AIRTAC pneumatic element ensures the running of pneumatic element to be stable and reliable.
2. The main structure of the vacuum packing machine is made of 304 Stainless Steel to ensure its elegant appearance as well as the anticorrosion in harsh caustic environment.
3. The conveyor is suitable for packing big item, and it could reduce the labor’s intensity, making the packing simple and convenient.
4. The display and control components on the control panel are in centralized layout to make the equipment work status absolutely clear and facilitate the operation of the machine.
5. The vacuum packing machine is equipped with heavy-duty mobile caster wheels and sturdy foot with good loading capacity and stability to make it easier as user moving the machine position.
Technical Parameter OF Vacuum Sealer

Model
DZQ-700L/S
DZQ-700L
Machine Dimensions(mm)
730 × 830 × 1800
730 × 830 × 1800
Sealer Type
Double Sealer
Single Sealer
Sealer Dimensions(mm)
700 × 10 × 2
700 × 10
Sealer Power Consumption(kW)
1
0.6
Pump Capacity(m3/h)
20
20
Pump Power Consumption(kW)
0.9
0.9
Electrical Requirement(v/Hz)
220/50
220/50
Production Cycle
2-3 Time/Min
2-3 Time/Min
Conveyor Adjustment Range (mm)
0-700
0-700
Distance Between Conveyor Working Table and Ground (mm)
370
370
Net Weight(kg)
105
105

    1. DZQ-700L External Strip Vacuum Packaging Machine

      Flexible and reliable packaging equipment systems

    1. DZQ-700L External Strip Vacuum Packaging Machine

      Multiple package sizes, Quick mold switching

    1. DZQ-700L External Strip Vacuum Packaging Machine

      Intelligent control / Precision parts

    1. DZQ-700L External Strip Vacuum Packaging Machine

      Complete Hermetic Seals Every Time

DZQ-700L External Strip Vacuum Packaging Machine
