Description
The automatic vacuum packaging machine provides higher productivity and capable of producing high levels of vacuum. Vacuum packaging removes air from the pouch and seals it in an airtight manner. Vacuum packaging extends the shelf-life and helps preserve the quality of the product. The vacuum packaging machines are equipped with microprocessor based digital controls and are sensor based for accuracy.
Features
Chamber with conveyor belt
Sensor based system for high accuracy
Microprocessor based
Digital display
Four preset programs
Cycle counter
Fully see-through lid
Emergency stop button
Electrical protection systems
Initial fresh air flushing for pouch protection
Power failure air intake system
Specification
Technical Data
|
QS1000VSA
|
Chamber dimensions (L × W × H) (mm)
|
1165 × 425 × 65
|
Seal length L2 (mm)
|
1000
|
Seal width (mm)
|
10
|
Max pack size (L × H) (mm)
|
160 × 60
|
Number of sealing jaws
|
2
|
Machine dimensions (L × W × H) (mm)
|
800 × 1420 × 1000
|
Voltage/frequency (V/Hz)
|
415/50/3P
|
Power (W)
|
2200
|
Pump capacity ( LPM )/(m3/h)
|
600/40
|
Weight (kg)
|
500
|
