Description
This vacuum packaging machine sealing line length is up to 1000mm, which can meet the requirement for high output. The machine has the advantages of high precision, stable lifting, rolling walking belt with accurate positioning; operator of the equipment need not manually adjust conveyor position, more time and power saving.ZBJ1000 pneumatic transmission chain type continuous vacuum machine has high hardware configuration.
Specifications
Application
The continuous rolling type vacuum packaging machine has technology skills and exquisite workmanship, operating system is whole sealing, complete machine can rinse with water, which is used in production of pickles or with liquid packing.
Technical indicators
Model
|
ZBJ1000
|
Vacuum Chamber size
|
L1125×W440×H100mm
|
Sealing size
|
990mm×8mm
|
Center distance
|
508mm(Conveyor belt)The effective size:350mm
|
Packing efficiency
|
240 to 360(Times/Hour)
|
Machine size
|
L1800×W1400×H1000mm
|
Power supply
|
380V 50HZ
|
Average power consumption
|
4kW
|
Weight
|
700KG
|
Optional function
|
Inflatable function, custom vacuum chamber dimensions, double sealing lines, Optional imported pump from Germany
|
