Description
The conveyor belt vacuum machine is expanding its range with an automatic machine, which offers an economic packaging solution for the widest variety of uses. This machine can be ideally matched to the desired application thanks to its many equipment options.
Features
Different chamber depths and widths
Chamber lid with different heights
Electric chamber lid hub
Height-adjustable transport conveyors in the chamber
Additionally equipped with conveyor
Variable arrangement of the sealing bars
Wide range of sealing systems
Can be combined with shrinking and drying units (SE 15/SE 130, TE 115/TE 130)
Advantages
Can be used for different conveyors
High variability regarding configuration and equipment
Very compact conveyor width
High economic efficiency
Simple operation
Parameters
Chamber dimension:
|
1,150 × 500 × 180 mm (width), 800 × 670 × 180 mm (depth)
|
Optional chamber lid heights:
|
120 mm
|
Sealing bar length:
|
1,150 mm, 800 mm
|
Sealing bar arrangements:
|
front/right, front/left, front
|
Pumps:
|
300, Roots 500, Roots 1000m³/h
|
Length of infeed conveyor:
|
W × D × H:
|
1,400 × 1,100 × 1,150 mm (width)
|
Length without infeed conveyor:
|
W × D × H:
|
1,050 × 1,350 × 1,150 mm (depth
|
