Vertical Vacuum Packing Machine

Description
Vertical vacuum packing machine composes of four preset programs, optional gas flushing, digital display, cycle counter, electrical protection systems.
Features
Vertical placement of pouch
Pneumatic Sealing
Sensor based system for high accuracy
Micro-processor based
Fully see through lid
Stainless steel contact parts
Emergency stop button
Initial fresh air flushing for pouch protection
Power failure air intake system
Sturdy and heavy gauge design
Specification

Technical Data
QS 300 VVT
Chamber dimensions (L1×W1×H1) (mm)
400 × 290 × 85
Seal length L2 (mm)
300
Seal width (mm)
3
Max pack size (mm)
300 × 250
Number of sealing jaws
1
Machine dimensions (L×W×H) (mm)
600 × 570 × 565
Voltage/frequency (V/Hz)
240/50
Power (W)
470
Pump capacity ( LPM )
330
Compressed air requirement
30LPM
Air pressure
6kg/cm2
Compressed air inlet
6mm, one touch
Weight (kg)
65
